Bộ nguồn Omron S8JX-G30024CD

Mã sản phẩm: S8JX-G30024CD

Thương hiệu: Omron

SKU: S8JX-G30024CD
Hãng sản xuất: Omron
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT

3.720.000₫ Giá thị trường: ~~4.125.000₫~~ Tiết kiệm: 405.000₫

Mô tả
Giới thiệu và hướng dẫn sử dụng

Mô tả

Omron S8JXG Series

Bảng hướng dẫn lựa chọn Bộ nguồn Omron Series S8JXG

Mã sản phẩm	Lắp đặt	Điện áp ngõ ra	Dòng điện	Kích thước
S8JX-G01505	Front Mount	5V	3A	39.5 mm
S8JX-G01505C	Front Mount	5V	3A	39.5 mm
S8JX-G01505CD	DIN Rail	5V	3A	50 mm
S8JX-G01505D	DIN Rail	5V	3A	50 mm
S8JX-G01512	Front Mount	12V	1.3A	39.5 mm
S8JX-G01512C	Front Mount	12V	1.3A	39.5 mm
S8JX-G01512CD	DIN Rail	12V	1.3A	50 mm
S8JX-G01512D	DIN Rail	12V	1.3A	50 mm
S8JX-G01515	Front Mount	15V	1A	39.5 mm
S8JX-G01515C	Front Mount	15V	1A	39.5 mm
S8JX-G01515CD	DIN Rail	15V	1A	50 mm
S8JX-G01515D	DIN Rail	15V	1A	50 mm
S8JX-G01524	Front Mount	24V	0.65A	39.5 mm
S8JX-G01524C	Front Mount	24V	0.65A	39.5 mm
S8JX-G01524CD	DIN Rail	24V	0.65A	50 mm
S8JX-G01524D	DIN Rail	24V	0.65A	50 mm
S8JX-G01548	Front Mount	48V	0.35A	39.5 mm
S8JX-G01548C	Front Mount	48V	0.35A	39.5 mm
S8JX-G01548CD	DIN Rail	48V	0.35A	50 mm
S8JX-G01548D	DIN Rail	48V	0.35A	50 mm
S8JX-G03505	Front Mount	5V	7A	39.5 mm
S8JX-G03505C	Front Mount	5V	7A	39.5 mm
S8JX-G03505CD	DIN Rail	5V	7A	50 mm
S8JX-G03505D	DIN Rail	5V	7A	50 mm
S8JX-G03512	Front Mount	12V	3A	39.5 mm
S8JX-G03512C	Front Mount	12V	3A	39.5 mm
S8JX-G03512CD	DIN Rail	12V	3A	50 mm
S8JX-G03512D	DIN Rail	12V	3A	50 mm
S8JX-G03515	Front Mount	15V	2.4A	39.5 mm
S8JX-G03515C	Front Mount	15V	2.4A	39.5 mm
S8JX-G03515CD	DIN Rail	15V	2.4A	50 mm
S8JX-G03515D	DIN Rail	15V	2.4A	50 mm
S8JX-G03524	Front Mount	24V	1.5A	39.5 mm
S8JX-G03524C	Front Mount	24V	1.5A	39.5 mm
S8JX-G03524CD	DIN Rail	24V	1.5A	50 mm
S8JX-G03524D	DIN Rail	24V	1.5A	50 mm
S8JX-G03548	Front Mount	48V	0.75A	39.5 mm
S8JX-G03548C	Front Mount	48V	0.75A	39.5 mm
S8JX-G03548CD	DIN Rail	48V	0.75A	50 mm
S8JX-G03548D	DIN Rail	48V	0.75A	50 mm
S8JX-G05005	Front Mount	5V	10A	40 mm
S8JX-G05005C	Front Mount	5V	10A	40 mm
S8JX-G05005CD	DIN Rail	5V	10A	50 mm
S8JX-G05005D	DIN Rail	5V	10A	50 mm
S8JX-G05012	Front Mount	12V	4.2A	40 mm
S8JX-G05012C	Front Mount	12V	4.2A	40 mm
S8JX-G05012CD	DIN Rail	12V	4.2A	50 mm
S8JX-G05012D	DIN Rail	12V	4.2A	50 mm
S8JX-G05024	Front Mount	24V	2.1A	40 mm
S8JX-G05024C	Front Mount	24V	2.1A	40 mm
S8JX-G05024CD	DIN Rail	24V	2.1A	50 mm
S8JX-G05024D	DIN Rail	24V	2.1A	50 mm
S8JX-G05048	Front Mount	48V	1.1A	40 mm
S8JX-G05048C	Front Mount	48V	1.1A	40 mm
S8JX-G05048CD	DIN Rail	48V	1.1A	50 mm
S8JX-G05048D	DIN Rail	48V	1.1A	50 mm
S8JX-G10005	Front Mount	5V	20A	50 mm
S8JX-G10005C	Front Mount	5V	20A	50 mm
S8JX-G10005CD	DIN Rail	5V	20A	56 mm
S8JX-G10005D	DIN Rail	5V	20A	56 mm
S8JX-G10012	Front Mount	12V	8.5A	50 mm
S8JX-G10012C	Front Mount	12V	8.5A	50 mm
S8JX-G10012CD	DIN Rail	12V	8.5A	56 mm
S8JX-G10012D	DIN Rail	12V	8.5A	56 mm
S8JX-G10024	Front Mount	24V	4.5A	50 mm
S8JX-G10024C	Front Mount	24V	4.5A	50 mm
S8JX-G10024CD	DIN Rail	24V	4.5A	56 mm
S8JX-G10024D	DIN Rail	24V	4.5A	56 mm
S8JX-G10048	Front Mount	48V	2.1A	50 mm
S8JX-G10048C	Front Mount	48V	2.1A	50 mm
S8JX-G10048CD	DIN Rail	48V	2.1A	56 mm
S8JX-G10048D	DIN Rail	48V	2.1A	56 mm
S8JX-G15005	Front Mount	5V	30A	60 mm
S8JX-G15005C	Front Mount	5V	30A	60 mm
S8JX-G15005CD	DIN Rail	5V	30A	66 mm
S8JX-G15005D	DIN Rail	5V	30A	66 mm
S8JX-G15012	Front Mount	12V	13A	60 mm
S8JX-G15012C	Front Mount	12V	13A	60 mm
S8JX-G15012CD	DIN Rail	12V	13A	66 mm
S8JX-G15012D	DIN Rail	12V	13A	66 mm
S8JX-G15024	Front Mount	24V	6.5A	50 mm
S8JX-G15024C	Front Mount	24V	6.5A	50 mm
S8JX-G15024CD	DIN Rail	24V	6.5A	56 mm
S8JX-G15024D	DIN Rail	24V	6.5A	56 mm
S8JX-G15048	Front Mount	48V	3.3A	50 mm
S8JX-G15048C	Front Mount	48V	3.3A	50 mm
S8JX-G15048CD	DIN Rail	48V	3.3A	56 mm
S8JX-G15048D	DIN Rail	48V	3.3A	56 mm
S8JX-G30012C	Front Mount	12V	27A	110 mm
S8JX-G30012CD	Front Mount	12V	27A	123 mm
S8JX-G30024C	Front Mount	24V	14A	119.2 mm
S8JX-G30024CD	DIN Rail	24V	14A	123 mm
S8JX-G30048CD	Front Mount	48V	7A	123 mm
S8JX-G60005C	Front Mount	5V	120A	150 mm
S8JX-G60012C	Front Mount	12V	53A	150 mm
S8JX-G60024C	Front Mount	24V	27A	150 mm
S8JX-G60048C	Front Mount	48V	13A	150 mm
S8JX-G30005CD	DIN Rail	5V	60A	123 mm
S8JX-G30005C	Front Mount	5V	60A	110 mm
